M/B MSI MAG B650 TOMAHAWK WIFI

Marca:
Código del producto: 68859 Categorías: ,
¡Oferta!

$ 262.900 Efectivo, transferencia o deposito

$ 278.674 Webpay, credito o debito

Disponibilidad: Sin stock
  • STOCK WEB: 6 disponibles
  • STOCK TIENDA: Sin Stock

  • Si es stock es igual o menor a 2 unidades, recomendamos llamar.
    Código del producto: 68859 Categorías: ,

    • Descripción

    MAG B650 TOMAHAWK WIFI
    Compatible con los procesadores AMD Ryzen™ serie 7000
    Soporta Memorias DDR5, hasta 6400+(OC) MHz
    Solución térmica de primera calidad: El diseño del disipador ampliado y el M.2 Shield Frozr están construidos para un sistema de alto rendimiento y para trabajar sin parar.
    Solución LAN 2,5G y Wi-Fi 6E de AMD: Solución de red mejorada para uso profesional y multimedia. Ofrece una conexión de red segura, estable y rápida.
    Lightning M.2: Funcionar con PCIe Gen 4 maximiza el rendimiento de las SSD basadas en NVMe
    Lightning USB 20G: puerto USB 3.2 Gen 2×2 incorporado, ofrece una velocidad de transmisión de 20 Gbps, 4 veces más rápido que el USB 3.2 Gen 1
    AUDIO BOOST 5: Premie a sus oídos con una calidad de sonido de estudio para una experiencia de juego más envolvente



    ESPECIFICACIONES

    CHIPSET AMD B650
    CPU SUPPORT Supports AMD Ryzen™ 7000 Series Desktop Processors
    Socket AM5
    MEMORY 4x DDR5, Maximum Memory Capacity 192GB
    Memory Support DDR5 6000+(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
    Max. overclocking frequency:
    • 1DPC 1R Max speed up to 6000+ MHz
    • 1DPC 2R Max speed up to 6000+ MHz
    • 2DPC 1R Max speed up to 6000+ MHz
    • 2DPC 2R Max speed up to 5400+ MHz
    ONBOARD GRAPHICS 1x HDMI™
    Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz*
    1x DisplayPort
    Support DP 1.4, maximum resolution of 8K 60Hz*
    *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
    EXPANSION SLOT 2x PCI-E x16 slot (Qty)
    Support x16/ x4
    1x PCI-E x1 slot (Qty)
    PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
    PCI_E2 Gen PCIe 4.0 supports up to x2 (From Chipset)
    PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)
    STORAGE 3x M.2 (Qty)
    M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
    M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
    M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
    6x SATA 6G (Qty)
    RAID Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices*
    Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
    * SATA_A1_A2 do not support RAID function.
    USB 2x USB 2.0 (Rear)
    4x USB 2.0 (Front)
    4x USB 3.2 Gen1 Type A (Rear)
    2x USB 3.2 Gen1 Type A (Front)
    3x USB 3.2 Gen2 Type A (Rear)
    1x USB 3.2 Gen2 Type C (Front)
    1x USB 3.2 Gen2x2 Type C (Rear)
    LAN Realtek® RTL8125B 2.5Gbps LAN
    WIRELESS / BLUETOOTH AMD Wi-Fi 6E
    The Wireless module is pre-installed in the M.2 (Key-E) slot
    Supports MU-MIMO TX/RX
    Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands
    Supports 802.11 a/ b/ g/ n/ ac/ ax
    Supports Bluetooth® 5.3**
    * Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11.
    ** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.
    AUDIO Realtek® ALC4080 Codec
    7.1-Channel High Performance Audio
    Supports S/PDIF output
    Supports up to 32-Bit/384 kHz playback on front panel
    INTERNAL I/O 1x Power Connector(ATX_PWR)
    2x Power Connector(CPU_PWR)
    1x CPU Fan
    1x Pump Fan
    6x System Fan
    2x Front Panel (JFP)
    1x Chassis Intrusion (JCI)
    1x Front Audio (JAUD)
    1x Tuning Controller connector(JDASH)
    2x Addressable V2 RGB LED connector (JARGB_V2)
    2x RGB LED connector(JRGB)
    1x TPM pin header(Support TPM 2.0)
    4x USB 2.0 ports
    2x USB 3.2 Gen1 Type A ports
    1x USB 3.2 Gen2 Type C ports
    LED FEATURE 4x EZ Debug LED
    BACK PANEL PORTS
    DisplayPort 1.4
    2.5G LAN Port
    USB 2.0 Port
    USB 3.2 Gen 1 5Gbps Type-A
    Wi-Fi / Bluetooth Antenna
    HD Audio Connectors
    Flash BIOS Button
    HDMI™ 2.1 Port
    USB 3.2 Gen 2 10Gbps Type-A
    USB 3.2 Gen 2×2 20Gbps Type-C
    Optical S/PDIF OUT
    OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
    PCB DIMENSION ATX
    243.84mmx304.8mm
