M/B GIGABYTE B450M DS3H WIFI

Marca:
Código del producto: 69284 Categorías: ,

$ 112.900 Efectivo, transferencia o deposito

$ 119.674 Webpay, credito o debito

Disponibilidad: Sin stock
  • STOCK WEB: 7 disponibles
  • STOCK TIENDA: 2 disponibles

  • Si el stock es igual o menor a 2 unidades, recomendamos llamar.
    Código del producto: 69284 Categorías: ,
  • Descripción

    P/N: B450M DS3H WIFI

    Procesador

    AM4 Socket: Supports AMD Ryzen™ 5000 series / Ryzen™ 5000 G-Series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 1st Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ 1st Gen Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors

    (Please refer “CPU Support List” for more information.)

    Chipset

    AMD B450

    Memoria

    4 x DDR4 DIMM sockets supporting up to 128 GB of system memory

    Dual channel memory architecture

    Support for DDR4 3600(O.C.)/3466(O.C.)/2933/2667/2400/2133 MHz memory modules

    Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

    Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

    Support for Extreme Memory Profile (XMP) memory modules

    (Please refer “Memory Support List” for more information.)

    Gráficos Integrados

    Integrated Graphics Processor:

    1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz(Note)

    * Support for HDMI 2.0 version and HDCP 2.2.(Note)

    Maximum shared memory of 16 GB



    (Note) Actual support may vary by CPU.

    Audio

    Realtek®Audio CODEC

    High Definition Audio

    2/4/5.1/7.1-channel

    * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

    Support for S/PDIF Out

    LAN

    Realtek® GbE LAN chip (1 Gbps/100 Mbps)

    Wireless Communication module

    Intel® Dual Band Wireless-AC 3168 (PCB rev. 1.0/1.2)

    WIFI 802.11a, b, g, n, ac, supporting 2.4/5 GHz Dual-Band

    BLUETOOTH 4.2

    Support for 11ac wireless standard

    Intel® Wireless-AC 9260 (PCB rev. 1.1)

    WIFI 802.11a, b, g, n, ac, supporting 2.4/5 GHz Dual-Band

    BLUETOOTH 5.1

    Support for 11ac 160MHz wireless standard

    AzureWave Wi-Fi AW-CB304NF (Realtek® RTL8821CE) (PCB rev. 1.3/1.4/1.5)

    WIFI 802.11a, b, g, n, ac, supporting 2.4/5 GHz Dual-Band

    BLUETOOTH 5.0

    Support for 11ac wireless standard

    (Actual data rate may vary depending on environment and equipment.)

    Puertos de Expansión

    1 x PCI Express x16 slot, running at x16 (PCIEX16)(Note)

    * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

    (The PCIEX16 slot conforms to PCI Express 3.0 standard.)

    1 x PCI Express x16 slot, running at x1 (PCIEX1_2)

    1 x PCI Express x1 slot

    (The PCIEX1_1 and PCIEX1_2 slots conform to PCI Express 2.0 standard.)

    (Note) Actual support may vary by CPU.

    Interfaz de Almacenamiento

    1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2* SSD support)

    * Actual support may vary by CPU.

    * Supports only M.2 SATA SSDs when using an AMD Athlon™-series/ 7th Gen. A-series or Athlon™ X4 APU.

    4 x SATA 6Gb/s connectors

    Support for RAID 0, RAID 1, and RAID 10

    * Refer to “1-7 Internal Connectors,” for the installation notices for the M.2 connector.

    USB

    CPU:

    4 x USB 3.1 Gen 1 ports on the back panel

    Chipset:

    2 x USB 3.1 Gen 1 ports available through the internal USB header

    6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

    Conectores Internos de E/S

    1 x 24-pin ATX main power connector

    1 x 8-pin ATX 12V power connector

    1 x CPU fan header

    1 x system fan header

    1 x M.2 Socket 3 connector

    4 x SATA 6Gb/s connectors

    1 x front panel header

    1 x front panel audio header

    1 x S/PDIF Out header

    1 x CPU cooler LED strip/RGB LED strip header

    1 x RGB LED strip header

    2 x addressable LED strip headers

    1 x USB 3.1 Gen 1 header

    2 x USB 2.0/1.1 headers

    1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)

    1 x serial port header

    1 x Clear CMOS jumper

    Conectores del Panel Trasero

    1 x PS/2 keyboard/mouse port

    1 x HDMI port

    4 x USB 3.1 Gen 1 ports

    4 x USB 2.0/1.1 ports

    2 x SMA antenna connectors (1T1R)

    1 x RJ-45 port

    3 x audio jacks

    Controlador de E/S

    iTE® I/O Controller Chip

    Monitorización H/W

    Voltage detection

    Temperature detection

    Fan speed detection

    Overheating warning

    Fan fail warning

    Fan speed control

    * Whether the fan speed control function is supported will depend on the cooler you install.

    BIOS

    1 x 128 Mbit flash

    Use of licensed AMI UEFI BIOS

    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

    Características Únicas

    Support for APP Center

    * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

    @BIOS

    EasyTune

    RGB Fusion

    Smart Backup

    System Information Viewer

    Support for Q-Flash

    Support for Xpress Install

    Software Incluido

    Norton® Internet Security (OEM version)

    cFosSpeed

    Sistema Operativo

    Support for Windows 10 64-bit

    Support for Windows 7 64-bit

    * To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.

    * Please download the “Windows USB Installation Tool” from GIGABYTE’s website and install it before installing Windows 7.

    Diseño

    Micro ATX Form Factor; 24.4cm x 21.5cm

    Otras Descripciones

    Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors’ website or 3rd party website.

    Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
